bt Standard 95W Outdoor PoE Injector, with 4 Pair PoE up to 95W of Power at 55VDC at 1.75 amp
Product Features:
PT-PSE108GBTR-OT-10DE belongs to 95W PoE Injector(Outdoor PoE Injector), is a single port midspan Injector with 4 Pair PoE up to 95 watts of power at 55 VDC at 1.75 amp.
It supports 10/100/1000Mbps/10GBps of data rates. Fully comply with IEEE802.3bt and remains compatible with any IEEE802.3af/at compliant devices. Equipped detecting chip inside, which will detect and classify PD before powering it, protecting non-PoE device.
Enclosed in an IP66 fire retardant metal case, designed for outdoor installation with installation kit PT-POT-MBK, no need to open the equipment. It operates with an input voltage of 100-240 Vac. The effective distance limitation of 100 meters over Cat5e/Cat6 cables.
Introduction:
95W IP67 Waterproof Outdoor Rated PoE Injector. Input 12-55Vdc, Output 55Vdc 1750mA, IEEE802.3af/at/bt, Operating Temperature: -40℃ to 65℃. 6KV Surge Protection.
Parameter:
| Parameter | Description |
| Key Features | bt standard 95W outdoor PoE injector |
| Part Number | PT-PSE108GBTR-OT-10DE |
| Ports condition | LAN *1, AC Input*1, PoE Output *1 |
| PoE output | 95W |
| Data rates | 10GBps |
| Power input | 12-55Vdc 10.0A Max |
| Power output | 55Vdc 1.75A |
| Regulatory Compliance | IEEE 802.3bt |
| RoHS Compliance |
| WEEE Compliance |
| Working Environment | Operating Temperature: -40℃ to 65℃ |
| Operating Humidity: 20% to 80%, non-condensation |
| Storage Temperature: -40℃ to 85℃ |
| Storage Humidity: 10% to 95%, non-condensation |
| Operating Altitude: up to 5000meters |
| AC Surge Protection | Line-Earth 1.2/50us (8/20us): 6KV |
| Line-Line 1.2/50us (8/20us):4KV |
| Mechanical Characteristics | Size: 176X 269 X 65mm |
| Weight: 1.8kg(3.97lb) |
| Safety Approvals | CE, FCC |
FAQ
Q: Are you manufacturer or trading company?
A: Manufacturer, and industry network total solution provider.
Q: Do you accept ODM/OEM?
A: Yes. We provide customized service.
Q: What is your minimum order quantity?
A: MOQ is 1 unit.
Q: What’s the payment type?
A: T/T, L/C,Western Union, Money Cram, Credit Card, Alipay, Cash.
Q: What’s the accepted trade terms?
A: EXW, FOB, CIF, FAS, CIP, FCA, CPT, DED, etc.
Q: How about shipping time?
A: Within 3-15 days after receiving full payment , but if you need OEM/ODM, the lead time depends on the specific specifications of the product.
Q: How about after-sales service?
A: 7/24 hours online and respond to user's field device problems in time.
Q: How about the warranty?
A: 5 years.
Company Introduction:
PROCET(Creative Lianjie Network Technology Co.,Ltd) was established in 2000. PROCET mainly R&D on the PoE (Power over Ethernet) series product, Outdoor PoE, indoor PoE, Lightning&surge protection PoE, -40℃ to +65℃ PoE, PoE splitter, PoE extender. We registered PROCET Technology Co., Ltd in HONGKONG in 2019.
Why Choose Us:
Operating since 2000
PROCET(Creative Lianjie Network Technology Co., Ltd) was established in 2000. PROCET mainly R&D on the PoE (Power over Ethernet) series product, Outdoor PoE, indoor PoE, Lightning&surge protection PoE, -40℃ to +65℃ PoE, PoE splitter, PoE extender. We registered PROCET Technology Co., Ltd in HONGKONG in 2019.
R&D Engineer Team
PROCET's engineers used PoE in 2002, and then mainly focused on PoE since 2003 the IEEE802.3AF standard comes out. We got our first paten on single-port PoE at the end of 2003.
Our PoE engineers have experience of more than 15 years now. They started to R&D the surgeon PoE using, and now they have a great contribution to our outdoor PoE series.
Production quality assurance
We kept our stable production workers, four QC with at least 4 years of experience to make sure the production.
We have aging testing, high-low temperature testing, surge testing, drop testing, swing testing before delivery.
We have CCC, CE,FCC,UL,TUV certification for our PoE.
OEM&ODM services
We do OEM services. Our MD engineer can help to design the LOGO, the label, the package, even the Housing.
We do ODM services too, special on the high power PoE solutions, the Boost-Buck voltage PoE, AC/DC surge PoE.
Packing: PT-PSE108GBTR-OT-10DE X1
Manual x 1
